歐亞木工機械廠是專業的木工機械電子裁板鋸系列制造商，生產各類規格的電子裁板鋸、往復鋸系列以及其他木工機械產品。
服務熱線：0757-25526552
產品分類
產品介紹
| 鋸切長度 Max cutting length: | 3270mm |
| 鋸片引申高度 Max saw rising: | 75mm |
| 主鋸片 ---- The main saw | |
| 鋸片直徑 Dia. of main saw blade: | Φ350mm |
| 鋸軸直徑 Dia. of main spindle: | Φ30mm |
| 轉速 Main saw arbor rotary speed: | 4800rpm |
| 副鋸片 ---- Auxiliary saw | |
| 鋸片直徑 Dia. of Auxiliary saw blade: | Φ160mm |
| 鋸軸直徑 Dia. of Auxiliary spindle: | Φ30mm |
| 轉速 Auxiliary saw arbor rotary speed: | 6500rpm |
| 鋸座 ---- Saw driving | |
| 前進速度 Speed of advance: | 0-45m/min |
| 后退速度 Speed of retreat: | 60m/min |
| 其它 ---- Others | |
| 主鋸電機 Main motor: | 11kw |
| 鋸座驅動電機 Saw block driving power: | 1.5kw |
| 凈重 Weight of machine: | 2800kg |
|
機器尺寸（長×寬×高） Overall dimension (L×W×H): 5 |
5960×3790×1930mm |
