產品介紹
|
技術參數 |
Technical specifications |
|
|
鋸切長度 |
Max cutting length: |
2680mm/3260mm/3800mm |
|
鋸片引申高度 |
Max saw rising: |
100mm/120mm |
|
鋸切寬度 |
Max cutting width: |
2680mm/3260mm/3800mm |
|
|
|
|
|
主鋸片The main saw |
|
|
|
鋸片直徑 |
Dia. of main saw blade: |
Φ400mm |
|
鋸軸直徑 |
Dia. of main spindle: |
Φ75mm |
|
轉速 |
Main saw arbor rotary speed: |
4800rpm |
|
|
|
|
|
副鋸片Auxiliary saw |
|
|
|
鋸片直徑 |
Dia. of Auxiliary saw blade: |
Φ180mm |
|
鋸軸直徑 |
Dia. of Auxiliary spindle: |
Φ45mm |
|
轉速 |
Auxiliary saw arbor rotary speed: |
6500rpm |
|
|
|
|
|
鋸座Saw driving |
|
|
|
最快速度 |
Max. Speed: |
100m/min |
|
|
|
|
|
其它 ---- Others |
|
|
|
主鋸電機 |
Main saw motor: |
15kw |
|
副鋸電機 |
Auxiliary saw motor: |
1.5kw |
|
鋸座驅動伺服電機 |
Saw block driving power: ; |
1.5kw伺服電機(AC Servomotor) |
|
自動送料伺服電機功率 |
Automatic feeding motor: |
1.5kw伺服電機(AC Servomotor) |
|
高壓送風電機 |
High pressure blower motor : |
3.8kw |
|
夾手最快速度 |
Auto feeding speed: |
80m/min |
|
使用氣壓 |
Working air pressure: |
6-8kg/cm平方 |
|
工作臺離地高度 |
Tabel height from floor: |
960mm |
|
凈重 |
Weight of machine: |
5000kg/5500kg |
|
機器尺寸（長×寬×高） |
Overall dimension (L×W×H): |
5950×6630×2010mm |
設備特點 Machine features
1.高速鋸車速度可達100米/分鐘。
High speed SAW CARRIAGE runs up to 100M/Min.
2.電腦定位送料機械手，配搭伺服電機可穩定工作于80米/分鐘。
CNC positioning feeding clamp, driven up to 80M/MIN by AC servo motor.
3.高強度機身，堅固的機身結構，確保鋸車的精密移動，使用多年后仍能保證很高的鋸切質量。
Rigid heavy duty machine frame , solid machine base , ensures precise carriage movements by providing maximum cutting quality for many yesrs.
4.整個機器的底座都有CNC加工中心來加工，使用臺灣一線品牌導軌和齒條，保證了鋸車導軌良好的平行度和垂直度。這個理想的解決方案使鋸切效果總能保持完美的垂直度和加工質量。
Parallelism and absolute perpendicularity of the guides on which the carriage runs is guaranteed by machining of the entire machine base on CNC machines, and first well-known Taiwan brands. The ideal solution gives a cut that is always perpendicular and perfect.
5.鋁合金鋸車，使用線性直線導軌和循環滾珠軸套來進行鋸車的升降，硬化導軌及齒條、齒輪：鋸車使用壽命長、性能好，精度高，鋸路直，適用于多塵的工作環境，精度穩定，提供最大鋸切能力。
Aluminum alloy SAW CARRIAGE. Linear prismatic guideways with recirculating ball bushings for the raising of the SAW CARRIAGE unit ：Long-life high performance, high accuracy, saw road is straight, suitable for dusty environment, the precision is stable, for maximum cutting ability.
6.送料行走機構采用進口硬化導軌及研磨級齒條、雙小齒輪，提供長期使用的精度。
機械手在高速度的情況下還能具備很高的定位精度。
Feeding running device applied with Imported hardened rails and heavy duty grounded-rack & double-pinion system, provide long-term accuracy. A very high precision pusher at high speed.
7.自動側壓系統，在帶循環滾珠軸套的棱形導軌上滑動，保證橫向鋸切的最佳精度，并減少鋸切時間，自動對正橫切角度。
Automatic side alignment device, device sliding on prismatic guideways with recirculating ball bushings always ensures precision on cross cuts and ensures reduces cutting times, automatic align the cross cutting at right angle.
8.高性能氣動式送料機械手，由進口的精密伺服驅動定位。
High performance pneumatic feeding clamp, positioned by Imported precision servo drive.
9.優質的電器配套系統，采用進口的PLC和伺服。
High quality electric auxiliary system, Imported PLC、servo motor and controlling system.
10.氣動浮臺和滾輪架：確保板材簡單輕松地移動，充分保護板料免于刮傷，也能防止已切過，暫時存放在臺面上的板料意外滑落。
Selectable air blowing table and precision roller table: Ensuring optimal sliding of the panels only where it is needed, it can fully protect the panels from scratch, and avoids accidental falling of cut panels temporarily stored on the tables.
