產品介紹
| 鋸切長度 Max cutting length: | 2670mm |
| 鋸片引申高度 Max saw rising: | 75mm/90mm |
| 主鋸片 ---- The main saw | |
| 鋸片直徑 Dia. of main saw blade: | Φ355mm/380mm |
| 鋸軸直徑 Dia. of main spindle: | Φ30mm |
| 轉速 Main saw arbor rotary speed: | 4800rpm |
| 副鋸片 ---- Auxiliary saw | |
| 鋸片直徑 Dia. of Auxiliary saw blade: | Φ180mm |
| 鋸軸直徑 Dia. of Auxiliary spindle: | Φ30mm |
| 轉速 Auxiliary saw arbor rotary speed: | 6500rpm |
| 鋸座 ---- Saw driving | |
| 前進速度 Speed of advance: | 0-50m/min |
| 后退速度 Speed of retreat: | 100m/min |
| 其它 ---- Others | |
| 主鋸電機 Main motor: | 11kw |
| 鋸座驅動電機 Saw block driving power: | 3kw |
|
伺服電機功率 Servo motor: |
1.5kw |
| 自動送料速度 Max.Auto feeding speed : | 50m/min |
| 凈重 Weight of machine: | 3300kg |
|
機器尺寸（長×寬×高） Overall dimension (L×W×H): 5 |
5400×5400×1660mm |
